In Compliance with Intel ATX12V 2.31
Active PFC design, power factor above 0.98
High efficiency LLC architecture, compatible with 90-264V input voltage range
The efficiency certification meets the US 80 PLUS certification gold standard, and the efficiency conversion reaches more than 90%
Short Circuit protection, Overpower Protection, Over voltage Protection
12cm silent fan, smart temperature control, low noise and large air volume
Modular design of power output, multiple combinations to meet diverse matching needs
The main output is designed with solid capacitors, which has a longer life and more stable output current
High stability and reliability, long service life, 100% aging test
Meet the safety requirements of CCC
Comply with 80 PLUS certification and RoHS environmental standards
| Model | HK750-51PP | |||||
| Output | DC voltage/ Current | 12V/50A | 5V/15A | 3.3V/15A | 5Vsb/2.5A | -12V/0.3A |
| Voltage Adjustment Range | 11.4-12.6 | 4.75-5.25 | 3.135-3.465 | 4.75-5.25 | 10.8-13.2 | |
| Current Adjustment Range | 0.5-45A | 0.3-15A | 0.3-15A | 0-2.5A | 0-0.3A | |
| Voltage Accuracy | ±5% | ±5% | ±5% | ±5% | ±10% | |
| Ripple | <120mV | <50mV | <50mV | <50mV | <120mV | |
| Input | Minimum Efficiency | 80 PLUS GOLD | ||||
| Voltage Range | 90-264VAC | |||||
| Surge Current | less than the ratings of its critical components (including bulk rectifiers, fuses, and surge limiting device) under all conditions of line voltage of 90-264Vac | |||||
| Standby power consumption | <1W | |||||
| Protection | Over-load | 715-975W, latch | ||||
| Over-voltage | +5V<7V, +12V<15.6V, +3.3V<4.7V | |||||
| Environment | Operating Temperature/ Humidity | 0～+35℃, 5～85﹪RH, no condensation | ||||
| Storage Temperature/ Humidity | -40～+55℃, 5～95﹪RH, with condensation | |||||
| Vibration | 5 to 17 Hz 0.048 inch double amplitude displacement, 17 to 199 Hz 0.73Gs acceleration, 200 to 500 Hz 0.33Gs acceleration, Frequency to be swept at a rate of 0.067 decades/minute (4 decades/hour). Dwell at resonant frequencies for 30 minutes. | |||||
| Production Compliance | Safety standards | GB4943.1-2011, GB17625.1-2012, GB/T9254-2008 | ||||
| EMC Standards | EN55022 Class B | |||||
| Hi-POT | Input to GND: Voltage 1800VAC Time 3.0S | |||||
| Other | Dimensions | 150*150*86mm | ||||
| Package | 6PCS/12KG | |||||
