• Complies with Intel TFX 12V Power Supply Standard
• Input Voltage Range: 180~264VAC
• Ball bearing fan with thermal control circuit
• Multiple protection functions: OVP, OPP, SCP
• High reliability with 100% full load aging test
• 1-year replacement warranty, 3-year total warranty
| Rated Power 200W | Input Parameters | 180-264VAC(47Hz-63Hz) 4A Max | |||
| Output Parameters | Load Range | Voltage Regulation | Ripple & Noise | ||
| Min | Max | ||||
| +5V | 0.2A | 10A | ±5% | ≤120mV | |
| +12V | 1A | 13A | ±5% | ≤50mV | |
| +5VSB | 0.05A | 2A | ±5% | ≤50mV | |
| +3.3V | 0.2A | 6A | ±5% | ≤50mV | |
| -12V | 0A | 0.3A | ±10% | ≤120mV | |
| Combined Output Power for +5V & +3.3V≤60W | |||||
| Standby Power Consumption | ≤3W(5VSB/0.05A) | ||||
| Protection Functions | OVP, OPP, SCP | ||||
| Operating Temperature | Temperature: 0°C ~ 45°C; Relative Humidity: 5% ~ 85% (non-condensing) | ||||
| Storage Temperature | Temperature: -40°C ~ 70°C; Relative Humidity: 5% ~ 95% | ||||
| EMI | Compliant with EN55032 Class B, GB9254 Class B | ||||
| Leakage Current to Ground | ≤3.5mA(264VAC/50Hz) | ||||
| MTBF | ≥50kh .MIL-HDBK-217F(25℃) | ||||
| Cooling Method | Forced air cooling with dual ball-bearing fan | ||||
| Packaging | 20units per carton | ||||
| Typical Dimensions | 175(L)×85(W)×70(H)mm | ||||
| Design Specification | Complies with Intel Flex 12V 1.0 Standard | ||||
| Application Fields | Mainly Used in Network Server, Industrial PC Applications | ||||
