• Side fan design, compatible with commercial rack-mount chassis installation
• Operating Temperature Range: 0℃~60℃
• Low Ripple, Low Noise
• Active PFC for high stability
• Intelligent temperature control circuit design for high reliability
• Multiple protection functions: OVP, OPP, SCP
| Rated Power 300W | Input Parameters | 90-264VAC(50Hz-60Hz) 5A Max | |||
| Output Parameters | Load Range | Voltage Regulation | Ripple & Noise | ||
| Min | Max | ||||
| +5V | 0.5A | 13A | ±5% | ≤120mV | |
| +12V | 0.5A | 20A | ±5% | ≤50mV | |
| +5VSB | 0A | 2A | ±5% | ≤50mV | |
| +3.3V | 0.5A | 10A | ±5% | ≤50mV | |
| -12V | 0A | 0.3A | ±10% | ≤120mV | |
| Combined Output Power for +5V & +3.3V≤90W | |||||
| Standby Power Consumption | ≤1W(5VSB/0.05A) | ||||
| Protection Functions | OVP, OPP, SCP | ||||
| Operating Temperature | Temperature: -10°C ~ 60°C; Relative Humidity: 5% ~ 85% (non-condensing) | ||||
| Storage Temperature | Temperature: -40°C ~ 85°C; Relative Humidity: 5% ~ 95% | ||||
| EMI | Compliant with EN55032 Class B, GB9254 Class B | ||||
| Leakage Current to Ground | ≤3.5mA(264VAC/50Hz) | ||||
| MTBF | ≥50kh .MIL-HDBK-217F(25℃) | ||||
| Cooling Method | Forced air cooling with dual ball-bearing fan | ||||
| Packaging | 10units per carton | ||||
| Typical Dimensions | 140(L)×150(W)×86(H)mm | ||||
| Application Fields | For Educational All-in-One Machine Application | ||||
