中文简体| Model | A21-215KFA1 | A21-215KFA2 | A21-215KFA3 | A21-215KFAA |
| Nominal Energy | 215KWh | 215KWh | 215KWh | 215KWh |
| Nominal Voltage | 768V | 768V | 716.8V | 716.8V |
| Nominal Capacity | 280Ah | 280Ah | 300Ah | 300Ah |
| Group Plan | 1P240S | 1P240S | 1P224S | 1P224S |
| Standard Charge | 56A | 56A | 56A | 56A |
| Standard Discharge | 56A | 56A | 56A | 56A |
| Max Charging Current | 150A | 150A | 150A | 150A |
| Max Continuous Discharging Current | 150A | 150A | 150A | 150A |
| Upper Limit Charging Voltage | 840V | 840V | 784V | 784V |
| Discharge Cut-off Voltage(Udo) | 660V | 660V | 628V | 628V |
| IP Grade | IP21 | IP54 | IP21 | IP54 |
| Cooling | For containers | Air cooling | For containers | Air cooling |
| Fire Fighting System | Heptafluoropropane | Heptafluoropropane | ||
| Communication | Modbus-RTU/TCP | Modbus-RTU/TCP | Modbus-RTU/TCP | ModbusRTU/TCP |
| Operating Temperature Range | -20-50℃ | -20-50℃ | -20-50℃ | -20-50℃ |
| Operating Humidity | ≤95% (No condensation) | ≤95% (No condensation) | ≤95% (No condensation) | ≤95% (No condensation) |
| Operating Altitude | ≤3000m | ≤3000m | ≤3000m | ≤3000m |
| Dimensions (L*W*Hmm) | 1040*750*2300 | 1100*800*2380 | 1040*750*2300 | 1100*800*2380 |
| Weight | 2100kg | 2300kg | 1900kg | 2100kg |
215KWh C&I Energy Storage Battery Specification.pdf
