HK300-41FP

1. In Compliance with Intel ATX12V 2.31
2. 8cm Silent Fan, Smart Temperature Control
3. Passive PFC, Single-Rail Forward Design, Low Standby Consumption
4. Compatible with 170~264V Input Voltage Range

产品规格

Model:	HK300-41FP
Dimensions:	125mm65mm100mm
Fan Size:	80mm*15mm
Conversion Efficiency:	>70%
Input:	220VAC
Output Voltage:	+12V	+5V	+3.3V	-12V	+5Vsb
Output Current:	14A	10A	6A	0.3A	2.0A
Max. Output Combined:		60W
Rated Power:	200W
Output Cable Connectors:	Main Power	CPU 12V	Type D 4Pin
Output Cable Connectors:	20+4pin	4pin	1
Main Output Cable:	310mm
